Reimers 75kW Vertical Boiler – 208V

Request Quote

• Vertical boiler design; very low floor space requirements
• Miniature boiler max. vessel volume 5ft3
• Maximum safety valve setting 100psi
• All boilers are manufactured in accordance with the requirements of the A.S.M.E. Boiler and Pressure Vessel Code and A.S.M.E. CSD-1. Each boiler bears the National Board Stamp “M”.
• Operating pressure range 0 – 85psig
• Heavy duty carbon steel pressure vessel. Vessel jacket and electrical enclosure powder coated (all 304 stainless steel optional)

To submit a quote request for this product please fill out the form below.
Product Quote Request
Name
Name
Quantity *

SKU: RVH75C3F Category: Tags: ,

Description

Features
• Vertical boiler design; very low floor space requirements
• Miniature boiler max. vessel volume 5ft3
• Maximum safety valve setting 100psi
• All boilers are manufactured in accordance with the requirements of the A.S.M.E. Boiler and Pressure Vessel Code and A.S.M.E. CSD-1. Each boiler bears the National Board Stamp “M”.
• Operating pressure range 0 – 85psig
• Heavy duty carbon steel pressure vessel. Vessel jacket and electrical enclosure powder coated (all 304 stainless steel optional)

Standard Equipment of Each Boiler Includes:
• A.S.M.E. pressure relief valve
• High pressure cutoff control with manual reset
• One (1) operating pressure control for all models equipped with two heating elements or two (2) staged operating pressure controls for all models equipped with three or four heating elements
• Low water level cutoff control with manual reset
• High water level cutoff control with automatic or manual reset.
• Magnetic contactors
• Internal branch circuit fusing
• Enable/Disable switch for each heating element
• Main supply power distribution block
• Indicator lights for POWER, REFILLING, HEATING and ALARMS

Output: 256.3 lb/hr
790lb ship weight

Dimensions:
Width: 28″ x Depth 37.5″x H 54.3″

Service Clearance – 36” on front (for element removal)
18” recommended remaining 3 sides
