At Auxo Medical, we’re committed to providing healthcare providers with cutting-edge imaging solutions that enhance surgical precision while prioritizing patient and staff safety. The DRTECH EXTRON series of C-arms stands out as a premium line of low-dose, high-performance systems designed for minimally invasive surgery (MIS), orthopedics, interventional procedures, and more. These fully digitalized C-arms deliver superb image quality with advanced noise reduction technology, user-friendly interfaces, and reinforced safety features—all at competitive pricing through our nationwide sales and service network.

Whether you’re equipping a spacious operating room or a compact clinic, the EXTRON series offers versatile configurations to meet your needs. With options like dynamic flat-panel detectors in 23×23 and 30×30 sizes, powerful 5 kW X-ray tubes, and integrated software for seamless workflows, these systems help reduce radiation exposure by up to 30% while maintaining exceptional clarity. Backed by a 36-month warranty on the DR panel and optional on-site training, DRTECH EXTRON C-arms are a reliable choice for modern healthcare facilities.

In this article, we’ll explore the key models available at Auxo Medical: the EXTRON 5 Premium C-Arm 30×30 Flat Detector, the DRTECH EXTRON 5 Premium C-Arm 23×23 Flat Detector, and the DRTECH EXTRON 3 Omni C-Arm 23×23 Flat Detector. Each model builds on DRTECH’s proven low-dose technology to support efficient, high-quality imaging.

Why Choose DRTECH EXTRON C-Arms?

The EXTRON series is engineered for demanding surgical environments, combining industry-leading low-dose imaging with practical features that streamline operations. Key benefits include:

• Ultimate Low-Dose Performance: Proven detectors and advanced technology minimize unnecessary radiation for physicians, staff, and patients, complying with stringent safety standards like IEC 60601-2-43.
• RNR (Real-time Noise Reduction) Technology: Analyzes motion and non-motion regions in real-time for optimal image processing, delivering low-noise images with up to 30% higher signal-to-noise ratio (SNR).
• User-Friendly Design: Intuitive controls, virtual collimators, and ergonomic setups make imaging easier for physicians and technicians, reducing procedure times.
• Enhanced Workflow and Productivity: Features like emergency radiography, mirroring systems, and integrated XConsole software boost efficiency in busy ORs.
• Reinforced Safety: Options for RAID 1-class storage, Dose Area Product (DAP) monitoring, and Air Kerma reporting ensure compliance and protection against system errors.

All models support a range of power requirements (120-127 VAC or 220-230 VAC) and operate in ambient conditions suitable for clinical use (10°C–35°C, 35–75% humidity). They come standard with green laser guides, hand/foot switches, thermal printers, and equipment protection covers. Optional upgrades, such as larger detector grids (324×324 mm) and on-site training (at an additional fee), further customize these systems for your facility.

Now, let’s dive into the specific models available.

EXTRON 5 Premium C-Arm 30×30 Flat Detector

The EXTRON 5 Premium C-Arm 30×30 Flat Detector is a high-end solution ideal for facilities requiring expansive imaging coverage. Its larger 30×30 dynamic flat-panel detector (IGZO TFT with CsI scintillator, 1,536×1,536 resolution, 148μm pixel pitch, and 16-bit A/D conversion) captures detailed views for complex procedures like vascular interventions and spinal surgeries.

Key Features:

• 43″ 4K IPS monitor (700 cd/m²) on a dual-hinge swivel arm, plus a 31.5″ 4K medical monitor (800 cd/m²).
• C-arm mobility: 165° orbital rotation (+120°/-45°), 200 mm horizontal movement, 500 mm vertical movement, ±12.5° panning, and ±235° pivot rotation.
• Advanced safety: Virtual collimator, iris/4-leaf collimator with leaf rotation, Air Kerma and DAP dose reporting, and emergency radioscopy.
• Integrated XConsole software on an Intel Apollo Lake N4200 quad-core CPU with Windows 10 IoT, supporting 1,920×1,080 resolution.
• Standard grid: 246×246 mm (200 lines/inch, 8:1 ratio); optional 324×324 mm grid available.

This model’s versatile monitor cart and comprehensive standard configuration make it perfect for high-volume ORs, where crisp, large-field imaging can improve accuracy and reduce repositioning. Request a quote today to learn more about pricing and installation options.

DRTECH EXTRON 5 Premium C-Arm 23×23 Flat Detector

For balanced performance in space-conscious environments, the DRTECH EXTRON 5 Premium C-Arm 23×23 Flat Detector offers top-tier imaging without compromise. Equipped with a 23×23 dynamic flat-panel detector (same high-spec IGZO TFT and CsI setup as the 30×30 model), it excels in orthopedic, pain management, and general surgical applications.

Key Features:

• Dual monitors: 43″ 4K (700 cd/m²) and 31.5″ 4K medical-grade (800 cd/m²) for superior visibility.
• Full C-arm range: Identical to the 30×30 model (165° orbital, 200 mm horizontal, 500 mm vertical, etc.), with reverse positioning for flexibility.
• Enhanced controls: Green laser guides (tube and detector sides, Class 2), wired 2-button foot switch, hand switch, and virtual collimator.
• Safety and monitoring: RAID 1 storage option, DAP (VacuDAP-C with 0.01 µGy/m² sensitivity), Air Kerma, and emergency radiography.
• Detector specs: 40-160 kVp energy range, 15W power consumption, and a standard 246×246 mm grid (optional larger grid).

This system’s real-time noise reduction and low-dose capabilities make it a go-to for procedures demanding precision in tighter spaces. With a compact yet powerful design, it’s an excellent upgrade for ambulatory surgery centers. Get a personalized quote and explore financing through Auxo Medical.

DRTECH EXTRON 3 Omni C-Arm 23×23 Flat Detector

The DRTECH EXTRON 3 Omni C-Arm 23×23 Flat Detector is the compact powerhouse of the series, tailored for clinics and ORs with limited space. As a single-body system, it incorporates core features from the premium EXTRON 5 and 7 lines but in a lightweight, all-in-one package—ideal for mobile imaging or smaller practices.

Key Features:

• 23×23 dynamic flat-panel detector with 5 kW X-ray tube for high-quality, low-dose output.
• 32″ articulating touch monitor paired with a 15.6″ operator console for intuitive control.
• Essential mobility: Green laser guide (detector side), leaf collimator, wired 2-button foot switch, and hand switch.
• Software and monitoring: XConsole imaging suite, Air Kerma, virtual collimator, and DAP support.
• Compact design: Mounted on a light monitor cart, with manuals and CD-ROM included for quick setup.

While more streamlined than the Premium models, the EXTRON 3 Omni delivers the same low-dose excellence and 36-month DR panel warranty, making it a cost-effective entry into advanced C-arm technology. It’s particularly suited for outpatient settings where space and budget are priorities. Submit your quote request to see how it fits your workflow.

Why Partner with Auxo Medical for DRTECH EXTRON C-Arms?

With nearly 30 years of expertise, Auxo Medical is your trusted source for new and refurbished imaging equipment. We offer:

• Nationwide Support: Sales consultation, onsite installation, and service across states like Virginia, Florida, Ohio, and more.
• Flexible Financing: Leasing, trade-ins, and transparent pricing to fit your budget—plus discounts for service agreement holders.
• Warranty and Training: Standard 36-month DR panel coverage, with optional 1-day onsite training to ensure smooth integration.
• Proven Reliability: Join satisfied clients who’ve optimized their ORs with Auxo Medical’s solutions.

Don’t just take our word—explore related options like the OEC 9800 C-Arm with Vascular Package for refurbished alternatives.

Ready to elevate your imaging capabilities? Browse our full C-Arms catalog or contact us for a free consultation. At Auxo Medical, we’re here to equip you for smarter, safer healthcare.
